Dishwasher Water Supply Connection

How to Connect a Whirlpool Dishwasher to the Water Supply


If water appears to be leaking from underneath the dishwasher, make sure that the water line from the household water supply is not damaged or cracked.

How to check the water supply line:

  1. Remove lower toe kick panel, using a flat-blade screwdriver
  2. Turn the plastic fasteners 1/4 turn counterclockwise to unlock them
  3. Remove panel
  4. The water hookup is located in the front left corner of the machine
  5. Inspect water connections and tighten as needed.


If you would like to download or view product literature for your appliance, please visit our Manuals and Literature page.
